SN74HC11DR 3-Channel AND Gate
3-channel, 3-input 2-V to 6-V 5.2 mA drive strength AND gate with buffered inputs and wide operating temperature range.
Key Features
- Buffered inputs for improved signal integrity
- Wide operating voltage range: 2 V to 6 V
- Wide operating temperature range: –40°C to +85°C
- Supports fanout up to 10 LSTTL loads
- Significant power reduction compared to LSTTL logic ICs
Applications
- Combining power good signals
- Enable digital signals
Product Description
This device contains three independent 3-input AND gates. Each gate performs the Boolean function Y = A ● B ● C in positive logic.
Device Information
| Part Number |
Package |
Body Size (Nominal) |
| SN74HC11DR |
SOIC (14) |
8.70 mm × 3.90 mm |
| SN74HC11NR |
PDIP (14) |
19.30 mm × 6.40 mm |
| SN74HC11NSR |
SO (14) |
10.20 mm × 5.30 mm |
| SN74HC11PWR |
TSSOP (14) |
5.00 mm × 4.40 mm |
| SN54HC11JR |
CDIP (14) |
21.30 mm × 7.60 mm |
| SN54HC11WR |
CFP (14) |
9.20 mm × 6.29 mm |
| SN54HC11FKR |
LCCC (20) |
8.90 mm × 8.90 mm |
